Elastic Recovery Mould

Elastic Recovery Mould

Product Code : EL-BTLE-10429

Quick Answer: The Elastic Recovery Mould is a set of three brass/gunmetal moulds built to specified shape, dimensions and tolerances, used to form the briquette specimens required for elastic recovery testing of bitumen. The mould’s ends (B & B’) act as clips and its sides (A & A’) form the sides of the mould, assembling into a briquette specimen with a total length of 75 ± 0.5 mm and dimensions A, B, C, D and E each held to ± 0.1 mm tolerances.

A set of three moulds made of brass /gunmetal with the shape, dimensions and tolerances. The ends B & B` are known as clips, and the parts A & A’ are known as sides of the mould. The dimensions of the mould shall be such that when properly assembled it will form a briquette specimen having the following dimensions.
Total length : 75 ± 0.5 mm
A = 36.5 ± 0.1 MM
B = 30.0 ± 0.1 MM
C = 17.0 ± 0.1 MM
D = 10.0 ± 0.1 MM
E = 10.0 ± 0.1 MM

Standards: EN13398; ASTM D113, D6084; AASHTO T51; NFT66

Contact Engineering Lab Equipment for your School, College Civil and Mechanical Engineering Lab Instruments. We are the best and renowned civil engineering lab equipment manufacturer, civil engineering lab equipments exporter, civil engineering lab equipment supplier, chemical engineering lab instruments, civil engineering lab equipments suppliers, civil engineering lab equipments exporters in Ambala, India.

Last Updated: September 2026

Related Products: Ductility Testing Apparatus, Refrigerated Ductility Test System, Standard Penetrometer, Ring and Ball Apparatus
