Automatic Flexure/Tension Machine

Automatic Flexure/Tension Machine

Product Code : EL-CTLE-10368

Quick Answer: The Automatic Flexure/Tension Machine determines the flexural strength of cement specimens and performs tensile tests on cement briquettes, using a beam loading system with a travelling weight driven by an electric motor that provides a constant increase in load throughout the test.
The machine is designed to accept either flexural or tensile attachments, which have to be ordered separately as accessories. It has a capacity of 5000 N and operates on 230 V, 50 Hz, 1 ph.
Technical Specifications :
Constant rate of loading
Dual range
Automatic stop at failure
Accepts flexural or briquette specimens
Single lever loading assures high accuracy
Wattage: 40 W
Dimensions: 510x1050x720 mm
Weight approx.: net 52 kg

Standards: ASTM C349 | ASTM C348 | EN 196-1 | ASTM C190

For this and other cement testing lab equipment, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India.
