Digital Double Door Drying Oven
Product Code : EL-LEAA-10521
Quick Answer: The Digital Double Door Drying Oven is a soil and aggregate drying oven built with a mild steel, powder-coated exterior and a stainless steel coated interior chamber for durability and corrosion resistance. It is fitted with a PID controller featuring microprocessor digital control and a safety thermostat backup for precise, safe temperature regulation, and is available in capacities from 100-500 Kg to 500-1000 Kg with maximum temperatures up to 300-400°C.
This range of ovens is designed for drying large quantities of soil and aggregate samples and maintains temperature in accordance with most B.S. and ASTM requirements. The 225 Lts. and 425 Lts. are economy models constructed with coated mild steel exterior and Stainless Steel coated interior chamber, which is both durable and corrosion resistant. These units meet the requirements of BS 1377 and are ideal for on-site laboratories and general soil and aggregate testing.
Technical Specifications :
Air-Flow Direction: Horizontal Air Flow, Duel Air Flow
Capacity: 100-500 Kg, 500-1000 Kg
Material for Construction: Stainless steel
No. of Shelves: 3
Type: Cabinet Ovens, Belt Conveyor Oven
Max Temperature (C): 200-300, 300-400
Options And Accessories:
Dial thermometer with collar fixing for door
Heavy duty shelves (on Request at an extra price)
Color of the Oven (Only on qty. greater than 3 Units)
The larger soil drying ovens are constructed with mild steel and a powder coated exterior and a Stainless Steel coated chamber, which is both durable and corrosion resistant. The door locking arrangement is easy and convenient, using a lever to lock and unlock with a half turn.
A Safety Thermostat is fitted inside the oven for safety purposes, and in case of failure of the PID controller, the safety thermostat will serve as the temperature controller. A High/Low switch is fitted on the panel of the oven for the heaters, allowing the heaters to burn all together or at half capacity. The least count division for viewing and setting the temperature is 0.1º C, and all sizes of oven are fitted with a PID controller having a microprocessor digital control as standard. The wiring of the heaters can be connected or disconnected by removing the side panels of the oven. Caster wheels with a locking arrangement are fitted below the oven for easy movability of the unit from one place to another, and all units come with an MCB tripping device in cases of any short circuit, overloading of voltage, and low voltage cut-off.
