Gear Pump Demonstration Unit
Product Code : EL-FMLE-10663
The gear pump is the most widely used of the positive action rotary pumps.
Two gear wheels operate inside a casing.
One is driven while the other rotates in mesh with it.
The liquid is carried around in the space between consecutive teeth and then ejected as the teeth mesh.
The pump has no valves. It is a positive displacement pump and will deliver against high pressures.
The output is a more even flow than that of a reciprocating pump.
It is particularly suitable for high-viscosity fluids.
A motor-driven gear pump, mounted on a stainless steel plinth with a water reservoir and pipework for continuous circulation.
The pump head and the water reservoir are manufactured from clear acrylic for maximum visibility
The pump speed is accurately controlled by an advanced electronic inverter.
This inverter also calculates the torque produced at the motor drive shaft, allowing the power used by the pump to be derived.
The conditioning electronics for the sensors and allows their readings to be displayed on the computer software.
FEATURES:
A small-scale gear pump demonstration unit, comprising of a water reservoir, pump, control valve, relief valve and interconnecting pipework, all mounted on a stainless steel base
Equipped with electronic measurement sensors for pump head pressure, flow rate and water temperature
Transparent pump head for visibility
Capable of being linked to a PC
Facilities for logging, processing and displaying data graphically
Offers a complete teaching package of coursework and laboratory investigation
Measurement of constant-speed pump performance, including the production of characteristic curves of outlet pressure against: Flow rate, Motor shaft power
Pump speed, Pump efficiency, Volumetric efficiency
Comparison of student calculations with computer results
Supplied with software providing full instructions for setting up, operating, calibrating and performing the teaching exercises.
SPECIFICATIONS:
Max flow rate: 6.5 l/m typical
Motor power rating: 250W, 230 V, 1PH
Max head: 25m
Max pump speed: 1,800rpm
DIMENSIONS AND WEIGHT:
L x W x H: 800-x600 x 800 mm
Weight: 90kg
