Laboratory Concrete Mixer
Product Code : EL-CTLE-10288
Laboratory Concrete Mixer (code EL-CTLE-10288) is a tilting vessel mixer for preparing concrete batches in mix design work, built around a frame-mounted steel vessel listed at 55/110 litres capacity. A 1½ HP motor turns the vessel at 20-22 RPM through a pulley arrangement, a hand wheel with counter weight tilts it to any angle, and the electrical supply needed is 220V, single phase, 50Hz AC.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Use | Preparing mix design of concrete |
| Vessel | Steel, 55/110 litres capacity, mounted on a frame |
| Drum speed | 20-22 RPM, by motor and pulley arrangement |
| Tilting | To any angle by hand wheel and counter weight, for mixing and discharge |
| Mixing blades | Fitted inside the vessel |
| Manual drive | Large pulley wheel allows the drum to be turned by hand during power failure |
| Motor | 1½ HP |
| Frame | Steel frame carrying the drum, pulley wheel and motor |
| Power supply | 220V, single phase, 50Hz, AC |
| Standards | BS and IS |
| Product code | EL-CTLE-10288 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Laboratory Concrete Mixer Used For?
Designing a concrete mix means making and testing trial batches until the proportions give the workability and strength required, and each batch must be mixed thoroughly before slump, cube or other tests are made. The materials are charged into the steel vessel, which the motor turns while the internal blades fold them together; the hand wheel and counter weight hold the vessel at the angle needed for mixing and then tip it to discharge the batch. If the power fails part-way through, the large pulley wheel lets the drum be turned by hand so that mixing can continue. The standards listed for this mixer are BS and IS.
What to Specify When Ordering
- Quantity — the number of concrete mixers required.
Frequently Asked Questions
What is the capacity of the mixer vessel?
The steel vessel is listed at 55/110 litres capacity and is mounted on a steel frame together with the pulley wheel and the motor.
How fast does the drum of the concrete mixer turn?
A motor and pulley arrangement rotates the vessel at 20-22 RPM while blades fixed inside it mix the material through.
How is the mixed concrete discharged?
The vessel can be tilted to any angle with the hand wheel and counter weight, which is used both to set the mixing position and to empty the drum.
What happens if the power supply fails during mixing?
The large pulley wheel lets the drum be rotated by hand when there is a power failure, so a batch already in the vessel can still be turned.
What motor and electrical supply does the mixer use?
A 1½ HP motor drives the mixer, and it is wired to work from a 220V, single phase, 50Hz AC mains supply.
What should an overseas enquiry for this mixer include?
Give the number of mixers, the destination country and the port or city of delivery, the delivery terms wanted such as FOB or CIF, any packing needs and the tender reference if there is one.
OEM Manufacturer
Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Laboratory Concrete Mixer at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its concrete testing equipment, from workability apparatus and specimen moulds to compression and flexure machines go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.
