Test Sieves

Product Code : EL-CTLE-10331

Test Sieves (code EL-CTLE-10331) are stainless steel sieves for particle size analysis, made with a sanitary construction that leaves no place for material to lodge. The frames are die stamped from 22 ga. sheet metal and polished inside and out, and the stainless steel sieve cloth carries no ink markings, with no rivets inside the frame and no epoxy bead where the cloth meets the wall.

Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.

Specifications

What Are the Test Sieves Used For?

A sieve analysis finds the grading of a granular material, that is, the share of particles falling between successive sieve sizes, which governs workability, packing and the suitability of aggregates and similar materials for their intended use. The operator nests the sieves with the largest opening at the top, places a weighed sample on the top sieve and shakes the stack by hand or mechanically, then weighs the material retained on each sieve. Because the cloth meets the frame wall in a smooth transition without an epoxy bead or inside rivets, retained material can be brushed out fully between tests.

What to Specify When Ordering

• Quantity — the number of sieves required.
• Cloth specification — sieve cloth to ASTM E11-20 or to ISO 3310.

Frequently Asked Questions

What are the sieve frames made from?
The frames are stainless steel, die stamped from 22 ga. sheet metal and polished on both the inside and the outside surfaces.

Which specifications does the sieve cloth follow?
The stainless steel sieve cloth is made to ASTM E11-20 or ISO 3310 specifications, and the standards listed for the sieves are BSS, ASTM and ISO standards.

Why are there no rivets or epoxy bead inside the frame?
Leaving out inside rivets and the epoxy bead gives a clean, smooth transition from the frame wall to the sieving surface, so no material is trapped and carried into the next test.

Is the sieve cloth marked with ink?
No. There are no ink markings on the sieve cloth, which keeps the sieving surface clean and free of anything that could rub off into a sample.

Why are the frames die stamped?
All standard frames are die stamped, so that each frame matches the next in fit and function and the sieves nest together consistently in a stack.

What information does an export enquiry need?
Send the number of sieves, the destination country and port or city, the delivery terms such as FOB or CIF, the packing requirements and any tender reference.

About the Supplier

Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd), Plot No. 43, Industrial Park, Sector 2, Growth Center, Saha, District Ambala, Haryana, India, supplies the Test Sieves together with its own concrete testing equipment, from workability apparatus and specimen moulds to compression and flexure machines. Engineering colleges, polytechnics, technical training institutes and research laboratories in India and overseas buy from the company, and tender and OEM enquiries are handled through the Tenders/OEM page.

Related Concrete Testing Equipment

• Concrete Flow Table Test Set — hinged 700 × 700 mm double steel table with stainless steel cone for concrete flow.
• Density of Fresh and Hardened Concrete — buoyancy balance with lifting water tank and specimen cradle for concrete density.
• Flexure Testing Machine Hand Operated — hand-pumped concrete beam tester with 0–100 kN gauge for 100 mm and 150 mm beams.
• Compaction Factor Test for Concrete Workability — trowels, 15.2 cm hand scoop, 61 cm rod and balance for the compaction factor test.
• Concrete Cube Mould — cast iron cube mould with base plate, made in metric and inch sizes.

See the full Concrete Testing Lab Equipment range or all Civil Engineering Lab Equipment.

Request a Quote

For this and other concrete testing lab equipment, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India. Quotations are given on request: send the number of sieves and the sieve cloth specification required and your delivery location through the contact page, or add the Test Sieves to the enquiry cart from this page.
