Soxhlet Extraction Apparatus

Soxhlet Extraction Apparatus

Product Code : EL-LEAA-10998

Quick Answer: This Soxhlet Extraction Apparatus accepts Soxhlet flasks of 50-500 ml capacity in small and large extraction sizes, electrically heated via hard-knitted glass yarn elements built into a mild steel/CRC sheet body available in 3- and 6-mantle configurations. It includes horizontal and vertical support rods with gatkas and screws to hold two flasks (glass parts not supplied), runs on single-phase 220/230V AC power, and has a temperature range of ambient to 300°C.

Soxhlet flask of 50-500ml capacity heat.
Extraction Small and Large size.
Electrical heating hard knitted glass yarn.
Mild Steel/CRC sheet outer body having provision for mild steel top duly painted for 3 and 6 mantles.
Horizontal and Vertical rods with gatka’s and screw to hold flask Supplied with 2 Nos.
Glass parts without supplied.

Technical Parameters :
Temperature: Ambient to 300°C
Housing Material: CRC or Mild Steel sheet duly powder coated
Insulation: Mineral Or Glass wool
Control Panel: ER 3/6 Nos. (As per requirement), 6 Nos. Toggle Switch, 6 Nos. Temperature Indicator
Power Consumption: Single Phase AC Supply 220/230VAC supply +- 10%
Optional: Top customer request double colour body
