Bending Moment Apparatus
Product Code : EL-AMLE-10615
Quick Answer:
The Bending Moment Apparatus is a structural mechanics test setup used to determine the bending moment and shear force at the hinge section of a beam under different loading conditions. It consists of a teak wood beam made of two hinged sections, together with a spring balance and adjustable screw arrangement that lets the operator calculate the bending moment for any load position and determine the shear force at the hinge. The unit includes a 1 metre span beam with supports, a weight set with loading hangers, a spirit level, and a technical manual, and it is used to plot influence line diagrams for bending moment and shear force.
PRINCIPLE OF OPERATION:
The long and short sections of the teak wood beam are connected by a hinge, and a spring balance with an adjusting screw, mounted at a fixed distance, enables the bending moment to be calculated for any load position. Another special attachment with an adjustable screw is also provided; together with a spring balance and its adjustable screw, this is used to determine the shear force at the hinge section.
SPECIFICATIONS:
Beam – 1 mtr. span with supports.
Bending moment measurement arrangement.
Shear force measurement arrangement.
Spirit level to restore the loaded beam to original position.
Weight set with loading hangers.
The technical manual accompanies the unit.
RANGE OF EXPERIMENTS:
Determination of shear force for different loading conditions.
Determination of bending moment for different loading conditions.
Influence line diagram for bending moment & shear force.
