Miniature Lathe Machine
Product Code : EL-CACLE-10876
Miniature Lathe Machine (code EL-CACLE-10876) is a compact mini CNC lathe used in educational institutions and training centres for CNC turning training on materials such as plastic, wax and steel. It has a 45° slant-bed construction, servo motors on both axes, a servo-driven cartridge-type spindle, LM guides, a 6 inch hydraulic hollow chuck, gang-type tooling, full enclosure and an X/Z rapid traverse of 18/18 m/min.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Type | Mini CNC lathe, compact |
| Use | CNC turning training in educational institutions and training centres |
| Materials | Plastic, wax, steel and others |
| Programmable functions | Spindle speeds and feed rates |
| Suitable components | Watch cases, small brass components; engineering college use |
| Bed | 45° slant bed construction |
| Axis drives | Servo motors on both axes |
| Spindle | Cartridge type, servo motor driven |
| CNC controller | 988 THz controller with absolute encoders |
| Guideways | LM guides on both axes |
| Chuck | Hydraulic hollow chuck, 6 in |
| Tooling | Gang type |
| Enclosure | Full enclosure |
| Rapid traverse | X/Z 18/18 m/min |
| Machine dimensions | 1050 × 600 × 1000 mm (L × W × H, approx.) |
| Machine weight | Approx. 210 kg |
| Product code | EL-CACLE-10876 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Miniature Lathe Machine Used For?
CNC turning training covers writing part programs, setting tools and work offsets, and running the program on a real machine. On this lathe the student clamps the work-piece in the 6 inch hydraulic hollow chuck, sets the tools on the gang-type tooling, and programs spindle speeds and feed rates to suit the material, whether plastic, wax or steel. The full enclosure keeps chips inside the machine while the servo-driven axes move at a rapid traverse of up to 18 m/min, and small parts such as watch cases and brass components can be made as practical exercises.
What to Specify When Ordering
- Quantity — the number of mini CNC lathes required.
Frequently Asked Questions
Where is the Miniature Lathe Machine used?
It is used in educational institutions, training centres and engineering colleges for CNC turning training, and is suitable for components such as watch cases and small brass parts.
Which materials can be machined?
With programmable spindle speeds and feed rates, the operator can cut a range of materials including plastic, wax and steel.
What bed and guideways does it have?
The lathe has a 45° slant-bed construction with LM guides on both axes, servo motors driving the X and Z axes and a servo-driven cartridge-type spindle.
What chuck and tooling are fitted?
Work is held in a 6 inch hydraulic hollow chuck, and the tools are arranged as gang-type tooling inside a full enclosure.
How fast are the rapid traverses, and how big is the machine?
Rapid traverse is 18 m/min on both the X and Z axes, and the lathe occupies about 1050 × 600 × 1000 mm with a weight of approximately 210 kg.
OEM Manufacturer
Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Miniature Lathe Machine at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its CAD and CAM laboratory machines and trainers go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.
