Slotted Weight
Product Code : EL-MAILE-10870
Slotted Weight (code EL-MAILE-10870) is a brass slotted weight set with hanger, used for the calibration of balances and weights in laboratories. The set contains one 50 g, nine 20 g, one 10 g and two 5 g slotted weights, the 50 g weight includes the hanger, and hanging weights from 50 g to 250 g can be made up in 5 g steps; it is packaged in a plastic storage box.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Material | Metal (brass) |
| Weights in set | One 50 g, nine 20 g, one 10 g and two 5 g slotted weights |
| Hanger | Included with the 50 g weight |
| Hanging load range | 50 g to 250 g in increments of 5 g |
| Corrosion | Corrosion resistant |
| Packing | Plastic storage box |
| Product code | EL-MAILE-10870 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Slotted Weight Used For?
Slotted weights hang on their hanger to apply a known load, so besides checking balances they are used in physics and mechanics practicals such as stretching springs to verify Hooke's law, loading a beam, wire or pulley system, and in force table and moment experiments. The hanger carries the 50 g base load, and slotted pieces are slipped onto its stem through their slots, so the load can be raised in 5 g steps up to 250 g without unhooking the hanger from the apparatus.
What to Specify When Ordering
- Quantity — the number of weight sets required.
Frequently Asked Questions
What weights are in the set?
The set contains one 50 g, nine 20 g, one 10 g and two 5 g slotted weights, giving 250 g in total including the hanger.
What loads can be hung?
With the hanger on the 50 g weight, hanging loads from 50 g to 250 g can be made up in increments of 5 g.
What material are the weights?
They are slotted metal weights of brass, which are corrosion resistant, and the set is packaged in a plastic storage box.
What are slotted weights used for?
They are used for calibration of balances and weights in laboratories, and slotted weights on a hanger also apply known loads in mechanics practicals.
How can the set be ordered?
An enquiry can be raised from the Add To Cart button here, or the number of sets and the delivery location can be sent via the contact page.
OEM Manufacturer
Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Slotted Weight at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its measuring instruments and instrumentation trainers for engineering laboratories go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.
