Lux Meter

Product Code : EL-MAILE-10819

Lux Meter (code EL-MAILE-10819) is a digital meter used to measure illumination, the amount of light falling on a surface, in lux or foot-candles. It covers 0 to 50 000 lux in 3 ranges with auto-ranging, a 4000 count LCD with a 61 segment bar graph and an accuracy of +5 percent of reading, uses a silicon photo diode detector of 82 × 55 × 7 mm and runs on a 9.0 V battery.

Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.

Specifications

What Is the Lux Meter Used For?

Illuminance, measured in lux or in foot-candles (FC), tells how much light reaches a surface, and it is checked in laboratories, classrooms, workshops, drawing offices and stores where a task needs a set level of lighting. The user places the separate photo detector flat on the work surface, facing the light, and reads the level from the meter; auto-ranging picks the right one of the 3 ranges up to 50 000 lux, and peak or maximum hold keeps a reading for recording. Readings taken at several points show how evenly a room or bench is lit.

What to Specify When Ordering

• Quantity — the number of lux meters required.

Frequently Asked Questions

What illumination range does the Lux Meter cover?
It measures from 0 to 50 000 lux in 3 ranges, switching between them automatically, and the reading can be shown in lux or in foot-candles (FC).

What accuracy is given for the readings?
The accuracy is +5 percent of reading, shown on a 4000 count LCD with a 61 segment bar graph.

What kind of light sensor is used?
Light is received by a silicon photo diode in a separate photo detector measuring 82 × 55 × 7 mm (H × W × D).

Which hold functions are available?
It offers peak hold and maximum data hold, so the highest or a chosen reading stays on the display for recording.

How is it powered?
It uses a single 9.0 V battery, with a low battery indication on the LCD and automatic power off when it is left on.

What comes with the meter?
The standard accessories are a soft carrying case and a manual. The meter body itself measures 148 × 70 × 40 mm (H × W × D).

OEM Manufacturer

Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Lux Meter at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its measuring instruments and instrumentation trainers for engineering laboratories go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.

Related Measuring Instruments

• Sound Meter — hand-held 30 to 130 dBA sound level meter with 1/2 inch electret microphone and max hold.
• Hygrometer Digital — electronic humidity and temperature meter with comfort level display and max/min memory.
• Aneroid Barometer — triple scale wall barometer in a 6 in brass case, reading 940 to 1080 mbar.

See the full Measurement and Instrumentation Lab Equipment range or all Mechanical Engineering Lab Equipment.

Request a Quote

For this and other measurement and instrumentation lab equipment, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India. For a price, send the number of lux meters required and the delivery location through the contact page; the Add To Cart button on this page also adds the Lux Meter to an enquiry.
